Practice Quiz in Diode Applications Part 1

This is the Online Practice Quiz in Diode Applications Part 1 from the book, Electronic Devices and Circuit Theory 10th Edition by Robert L. Boylestad. If you are looking for a reviewer in Electronics Engineering this will definitely help. I can assure you that this will be a great help in reviewing the book in preparation for your Board Exam. Make sure to familiarize each and every questions to increase the chance of passing the ECE Board Exam.

Start Part I of the Online Practice Quiz

Quiz in Diode Applications Question 1. Determine ID. A. 0 mA B. 1.893 mA C. 2.036 mA D. 2.143 mA Question 2. Rectifiers are commonly used in battery chargers. A. True B. False Question 3. Determine ID2. A. 6.061 mA B. 0.7 mA C. 3.393 mA D. 3.571 mA Question 4. Determine ID2. A. 29.40 mA B. 30.30 mA C. 14.70 mA D. None of these Question 5. Determine the value of the load resistor. A. RL = 5 kΩ B. RL = 5.5 kΩ C. RL = 6 kΩ D. None of these Question 6. List the categories of clippers. A. Series B. Parallel C. Series and parallel D. None of these Question 7. Determine V2. A. 3.201 V B. 0 V C. 4.3 V D. 1.371 V Question 8. Determine the current level if E = 15 V and R = 3 kΩ. A. 0 A B. 4.76 mA C. 5 mA D. 5 A Question 9. What is the logic function of this circuit? A. Positive logic AND gate B. Positive logic OR gate C. Negative logic AND gate D. Negative logic OR gate Question 10. What is the voltage measured from the negative terminal of C4 to the negative terminal of the transformer? A. –10 V B. –20 V C. 10 V D. 20 V
